Florian Modular Synthesiser

White Panel Version What if a Roland SH-2 had a modular baby with an ARP Odyssey, but the midwife was a mad English scientist?

This product is forthcoming and will be available soon!

Description

Florian is our first dual VCO synthesiser! The name is a tribute to Florian Schneider-Esleben, who passed the same week that we conceptualised this synthesiser.

Florian features the following sub-modules, all behind a single 42HP panel:

  • 2 x XVCO, our legendary discrete VCO based on the Roland 100M design
  • Sub oscillator offering -1 octave square, -2 octave square, and -2 ocatve pulse
  • Digital ring modulator, taking VCO1 and VCO2 as it’s X and Y input.
  • Voltage controlled filter offering lowpass, bandpass, and highpass responses, based on Roland 700 multimode filter
  • ADSR based around AS3310 chip, offering normal and inverted outputs as well as CV of level
  • ARP influenced VCA with ADSR/gate/drone options
  • ARP influenced A/R generator with looping option
  • LFO1: triangle
  • LFO2: saw/triangle/ramp with sync option

Product Specifications

5V draw

0mA

Depth

39mm

Width

42HP

12V draw

249mA

-12V draw

111mA
